The go-to choice for efficient climate control
A VAV terminal is a zone-level flow control device that plays a pivotal role in HVAC systems. In effect, it is a calibrated air damper with an automatic actuator, so when cooling demand increases, the VAV terminal opens up, allowing more cool air to flow into the occupied space. Conversely, as the load decreases, the VAV terminal reduces the air supply.
These terminals consist of essential components: a thermostat, actuator, controller, damper, and, in the case of pressure-independent types, an airflow sensor. By dynamically adjusting airflow based on demand, VAV terminals contribute to energy efficiency and personalised comfort.
Products
Series Flow Fan-powered (TCSB)
Newly redesigned series flow units with improved features specifically designed for quiet operation and improved space comfort.
- 100-4400 CFM
- Solo/Sync EC Motor Control Technology
- Metasys® BACnet DDC (Direct Digital Control)
Ultra-quiet Series Flow Fan-Powered (TCSQ)
Newly redesigned ultra-quiet series flow units with improved features specifically designed for quiet operation and improved space comfort.
- 100-4400 CFM
- Solo/Sync EC Motor Control Technology
- Metasys® BACnet DDC (Direct Digital Control)
- Integrated Sound Attenuator for Ultra-Quiet Performance
Parallel Fan Powered (TVS)
A popular option for heating and cooling perimeter zones.
- 100–4100 CFM
- PSC or EC motor options
- AHRI 880 and ETL certified
Single Duct (TSS)
All the benefits of single duct units while performing at extremely low sound levels.
- AHRI 880 and ETL certified
- Lower CFM values
- Robust inlet collar for easy installation
Single Duct Low Height (TSL)
Perfect for retrofit projects or anywhere with congested ceiling spaces.
- Maximum height of 10 inches
- Electric heat units are flippable
- AHRI 880 and ETL certified
Dual Duct (TDS)
Ideal for providing alternative ventilation and humidity control strategies.
- AHRI 880 and ETL certified
- Air measuring probe provides lower CFM
- Efficiency with lower installed costs
Series Fan Powered (TCS)
Units offering improved space comfort and specifically designed for quiet operation.
- 100–4600 CFM
- OSHP-OSP certified
- PSC or EC motor options
Series Fan Powered Low Height (TCL)
Units offering improved space comfort and specifically designed for quiet operation.
- 100–4100 CFM
- Maximum height of 11″–12″
- Perfect for retrofits or congested spaces
Parallel Fan Powered Low Height (TVL)
A popular option for heating and cooling perimeter zones.
- 100–4100 CFM
- Maximum height of 10.5″–12″
- Perfect for retrofits or congested spaces
Supply Exhaust Units
Units available in galvanised (TSX) and stainless (TXS-S) construction.
- Retrofit terminal units for air volume control
- Controls supply and/or exhaust air
DOAS Fan Powered
Units that include an integral chilled water sensible only coil at the plenum air inlet.
- Measures and controls to minimum ventilation rates
- Optional hot water reheat available
Johnson Controls Offers a Broad Portfolio of Products
Blower Coil Units
These units feature a belt-driven fan and are available in horizontal, vertical, and reduced footprint vertical designs.
